VSP

Applications

●Suitable for clean water without abrasive particles and liquids that are not chemically aggressive to pump manufacturing materials.

● They are easy to use and affordable, making them ideal for domestic use, especially in combination with small pressure units for distributing water and for irrigation of gardens and land. The pump is equipped with a flapper check valve.

●One of the main features of this pump is its ability to maintain stable water pressure. It keeps your water heater running properly, ensuring you have a continuous supply of hot water when you need it. Whether you're taking a refreshing shower in the morning or washing the dishes after a meal, consistent water pressure makes all the difference.

●It is worth noting that in order for the pump to function optimally and extend its service life, it should be installed in a closed environment. It can be protected from severe weather such as heavy rain, strong winds and extreme temperatures. By protecting your pump in this way, you can rely on it to provide you with a steady flow of clean water for many years to come, supporting your daily life and enhancing the beauty and functionality of your home and garden.

Motor

● Two- pole induction motor(n=2850 r.p.m)

● Insulation Class B

● Protection IP44

● Continuous service S1

● Thermal protector

● Single-phase 220V/50Hz, 60Hz if request

Operating conditions

● Liquid temperature up to 80°C

● Ambient temperature up to 40°C

● Total suction lift up to 9m

Component Construction

● Pump body: Cast iron+AISI304 SS insert

● Pump support: Pure brass

● Motor housing: Aluminum

● Impeller: Brass

● Motor shaft: AISI304 SS

● Mechanical seal: Ceramic/Graphite
